Invicta SNLX12V300BT 12V 300Ah LiFePO4 Bluetooth Battery

Invicta SNLX12V300BT 12V 300Ah LiFePO4 Bluetooth Battery

The SNLX12V300BT is a 12V 300Ah Lithium Iron Phosphate battery with integrated Bluetooth monitoring, CAN Bus communication, and a high-performance BMS rated for 300A maximum discharge current. IP67 rated and IEC62619 certified, it supports configurations up to 4 units in series and 16 in parallel, backed by a 7-year full replacement warranty.

Product overview

The Invicta SNLX12V300BT is part of the Xero range, designed for applications that demand high-capacity, long-cycle energy storage in demanding environments. Built around aluminium-encased prismatic cells and laser-welded busbars, the battery is engineered for structural integrity and consistent electrical performance across its rated cycle life of 3,000+ cycles at 100% depth of discharge.

The high-performance BMS supports a continuous discharge of 150A and a pulse discharge of 300A, with the flexibility to wire up to 16 batteries in parallel or 4 in series, including combined 4S+4P configurations. This makes the SNLX12V300BT well suited to large-scale off-grid solar storage, heavy-duty marine applications, commercial vehicle auxiliary power, and industrial energy systems.

Bluetooth connectivity links to the free Invicta app, providing real-time visibility over key battery metrics from a mobile device. The CAN Bus interface adds a further layer of integration capability for systems requiring precise battery data communication with compatible inverters, chargers, and monitoring platforms.

Features and benefits

12V 300Ah LiFePO4 with aluminium-encased prismatic cells: The prismatic cell format and aluminium enclosure deliver structural rigidity and efficient thermal management across the full capacity of the battery.

300A maximum discharge current: Supports a maximum discharge current of 300A, making it capable of handling high-draw loads in demanding commercial and off-grid applications.

3,000+ charge cycles at 100% DOD: Rated for over 3,000 full charge and discharge cycles, providing a long service life that significantly reduces replacement frequency compared to lead-acid alternatives.

High-performance BMS with 500A pulse discharge: The integrated BMS delivers a pulse discharge of 500A and continuous discharge of 150A, while actively protecting against overcharge, over-discharge, short circuit, and temperature extremes.

Flexible series and parallel configurations: Supports up to 4 units in series, 16 in parallel, or a combined 4S+4P configuration, allowing scalable battery bank designs across a wide range of voltage and capacity requirements.

Bluetooth monitoring via Invicta app: Connects to the free Invicta app via Bluetooth, providing real-time tracking of key battery metrics including state of charge, voltage, and system health directly from a mobile device.

CAN Bus communication: The open CAN Bus protocol enables high-accuracy integration with compatible inverters, solar regulators, and battery management systems for advanced remote monitoring and control.

IP67 waterproof and dustproof rating: The rugged case carries an IP67 ingress protection rating, with internal components fixed securely to minimise vibration impact in mobile and off-road applications.

Laser-welded busbars: Laser-welded busbar connections reduce resistance at cell interconnects, contributing to consistent performance and long-term reliability across the battery's service life.

7-year full replacement warranty: Backed by a 7-year full replacement warranty with nationwide service support, providing long-term confidence in the product's reliability.

IEC62619 certified: Carries IEC62619 certification, confirming compliance with international safety standards for secondary lithium cells and batteries used in industrial applications.

Technical specs

Frequently asked questions

Can the SNLX12V300BT be configured in a 48V system?
Yes. Wiring 4 units in series produces a 48V battery bank. Always confirm that your inverter, charger, and BMS are rated for 48V operation before configuring in series.

What app is used to monitor the SNLX12V300BT via Bluetooth?
The SNLX12V300BT connects to the free Invicta app, available for download on compatible mobile devices. The app provides real-time visibility over key battery metrics including state of charge and voltage.

What is the difference between the CAN Bus and Bluetooth monitoring options?
Bluetooth connects to the Invicta app for mobile monitoring of battery metrics. The CAN Bus interface provides higher-accuracy data communication with compatible inverters, chargers, and battery management systems for deeper system integration.

Is the SNLX12V300BT suitable for solar storage applications?
Yes. The battery's high capacity, long cycle life, and CAN Bus integration make it well suited to off-grid solar storage systems. Contact us to confirm compatibility with your specific solar regulator or inverter setup.

What type of charger is required for the SNLX12V300BT?
The SNLX12V300BT requires a LiFePO4-compatible 12V charger. Using a charger not rated for LiFePO4 chemistry may damage the battery or void the warranty. Contact us for charger recommendations suited to this battery.
