Invicta SNLX12V100BT 12V 100Ah LiFePO4 Bluetooth Battery

Invicta SNLX12V100BT 12V 100Ah LiFePO4 Bluetooth Battery

The SNLX12V100BT is a 12V 100Ah Lithium Iron Phosphate battery with integrated Bluetooth and CAN/RS485 communication, a built-in BMS, and IP67 ingress protection. Rated for 150A continuous discharge with a 500A pulse, it supports configurations up to 4 in series and 16 in parallel, with over 3,000 cycles at 100% depth of discharge.

Product overview

The Invicta SNLX12V100BT is part of the Xero 12V range, designed as a direct replacement for similarly sized lead-acid batteries across a wide range of applications. Built on Lithium Iron Phosphate technology, it delivers significantly higher cycle life, lower weight, and greater usable capacity than equivalent SLA batteries, while adding advanced communication and configuration capabilities.

At 12.5kg, the SNLX12V100BT weighs less than half of a comparable SLA battery, reducing total system weight in mobile and weight-sensitive installations. The IP67 rating seals the battery against dust and water ingress, making it suitable for exposed environments in Australian conditions. Detachable mounting feet allow direct, secure installation to the application using a screwdriver, without requiring additional mounting hardware.

Bluetooth connectivity enables real-time battery monitoring from a mobile device, while the CAN/RS485 interface supports integration with compatible inverters, chargers, and battery management systems. The flexible series and parallel configuration support, up to 4S, 16P, or a combined 4S+4P, allows the SNLX12V100BT to serve as the foundation for scalable battery bank designs across a range of voltage and capacity requirements.

Features and benefits

12V 100Ah LiFePO4 chemistry: Lithium Iron Phosphate technology delivers a stable, safe energy output with an extremely low self-discharge rate, designed as a direct replacement for similar-sized lead-acid batteries.

3,000+ charge cycles at 100% DOD: Rated for over 3,000 full charge and discharge cycles, providing up to 10 times the cycle life of an equivalent SLA battery and significantly reducing total cost of ownership over the battery's service life.

150A continuous discharge, 500A pulse: Supports a maximum continuous discharge current of 150A and a 500A pulse discharge for up to 3 seconds, handling high-draw loads across demanding commercial and off-grid applications.

Bluetooth and CAN/RS485 communication: Built-in Bluetooth allows real-time battery monitoring from a mobile device, while the CAN/RS485 interface enables integration with compatible inverters, chargers, and battery management systems for advanced system control.

Flexible series and parallel configuration: Supports up to 4 units in series, 16 in parallel, or a combined 4S+4P configuration, allowing scalable battery bank designs across a wide range of voltage and capacity requirements.

Integrated BMS: The on-board Battery Management System actively protects the battery against overcharge, over-discharge, short circuit, and temperature extremes, ensuring safe operation across all supported applications.

IP67 rated: Fully sealed against dust and water ingress to IP67, making the SNLX12V100BT suitable for exposed installations in harsh outdoor and mobile environments.

Detachable mounting feet: Mounting feet can be attached or removed with a screwdriver, allowing the battery to be secured directly to the application without additional mounting hardware or brackets.

High energy density, low weight: At 12.5kg, the SNLX12V100BT weighs less than half of an equivalent SLA battery, significantly reducing total system weight in caravans, mobility devices, and portable power applications.

IEC62619 certified: Certified to IEC62619, confirming compliance with international safety standards for secondary lithium cells and batteries used in industrial and consumer applications.

Technical specs

Frequently asked questions

What is the difference between the SNLX12V100BT and the SNLX12V120BT?
The SNLX12V100BT has a 100Ah capacity and weighs 12.5kg, while the SNLX12V120BT has a 120Ah capacity and weighs 14kg. Both feature Bluetooth and CAN/RS485 communication, IP67 rating, and detachable mounting feet. Contact us if you need help selecting the right capacity for your application.

What app is used to monitor the SNLX12V100BT via Bluetooth?
Specific app details are not confirmed in the available source data. Contact us for information on compatible monitoring applications for the SNLX12V100BT.

Can the SNLX12V100BT be configured in a 48V system?
Yes. Wiring 4 units in series produces a 48V battery bank. Always confirm that your inverter, charger, and BMS are rated for 48V operation before configuring in series.

Is the SNLX12V100BT a direct replacement for a lead-acid battery?
Yes. The Xero 12V range is specifically designed as a direct replacement for similarly sized lead-acid batteries. The M8 terminal and compact dimensions support straightforward swap-out in most applications. Contact us to confirm fitment for your specific setup.

What type of charger is required for the SNLX12V100BT?
The SNLX12V100BT requires a LiFePO4-compatible 12V charger with a maximum charge current not exceeding 100A. Using a charger not rated for LiFePO4 chemistry may damage the battery or void the warranty. Contact us for charger recommendations suited to this battery.
