Invicta SNL36V100BT 36V 100Ah LiFePO4 Bluetooth Battery

Invicta SNL36V100BT 36V 100Ah LiFePO4 Deep Cycle Lithium Battery with Bluetooth

The SNL36V100BT is a 36V 100Ah LiFePO4 deep cycle lithium battery from Invicta with integrated Bluetooth monitoring, aluminium-encased prismatic cells, solid busbar connectors, and an integrated BMS. IEC62619 and IEC62133/UL1642 certified, with 2000+ genuine cycles at 100% DoD and a 7-year warranty in approved applications. Suited to 4WD, caravan, marine, and commercial and industrial deep cycle applications.

Product overview

The Invicta SNL36V100BT is a 36V deep cycle LiFePO4 battery designed for demanding applications requiring a reliable, high-cycle 36V lithium power source with wireless monitoring capability. The aluminium-encased prismatic cell construction with bolted busbar intercell connectors is designed to resist vibration and movement in off-road, marine, and caravan environments. The integrated BMS is engineered for the Australian market and provides automatic protection against overcharge, over-discharge, extreme temperatures, and short circuits.

The Bluetooth feature allows the user to monitor charge, discharge, capacity, temperature, voltage, and BMS safety features from up to 5 metres away via a free Apple or Android application. This is particularly useful when the battery is installed in a hard-to-reach location such as behind a seat or in a battery box. Note that Invicta Bluetooth batteries cannot be connected in series. The SNL36V100BT is available as a standalone 36V solution for applications where series connection of 12V Bluetooth batteries is not suitable.

The SNL36V100BT is independently tested in Australia and has achieved IEC62619 certification covering the complete battery including cells and BMS, and IEC62133/UL1642 certification at cell level. The battery completed 2000+ genuine cycles at 100% DoD over 1000 days of testing under Australian conditions including significant temperature variations. The 7-year full replacement warranty is available in approved applications, backed by SPB with over 25 years in the energy storage industry.

Features and benefits

LiFePO4 prismatic cells in aluminium enclosure: High-grade LiFePO4 prismatic cells in a rigid aluminium enclosure with bolted busbar intercell connectors provide stable chemistry, long cycle life, and resistance to vibration in demanding environments.

Integrated Australian-market BMS: The integrated BMS is engineered for the Australian market and provides automatic protection against overcharge, over-discharge, temperature, and short circuits. Developed in the same factory as the cells and tested to IEC62619 standards.

Bluetooth monitoring from up to 5 metres: The built-in Bluetooth module allows monitoring of charge, discharge, capacity, temperature, voltage, and BMS safety features from up to 5 metres via a free Apple or Android app. Useful for batteries installed in hard-to-reach locations. Cannot be connected in series.

IEC62619 and IEC62133/UL1642 certified: IEC62619 covers the complete battery including all cells and BMS, verifying safety and performance under high impact, thermal abuse, and overcharge/over-discharge conditions with annual factory audit. IEC62133/UL1642 certifies safety and performance at the cell level across the entire Invicta range.

2000+ genuine cycles at 100% DoD: Independently tested in Australia to 2000+ genuine cycles at 100% depth of discharge over 1000 days of operation under Australian temperature conditions, providing up to 8 times the cycle life of SLA batteries.

Up to 4 batteries in parallel: Supports parallel configuration of up to 4 units for increased capacity. Cannot be connected in series.

7-year warranty in approved applications: Backed by a 7-year full replacement warranty in approved applications, supported by SPB with over 25 years in the energy storage industry.

Not for under-bonnet or starting applications: The SNL36V100BT is a deep cycle battery and is not suited to under-bonnet or engine starting applications unless specifically approved by Invicta.

Technical specs

Frequently asked questions

What applications is the SNL36V100BT suited to?
The SNL36V100BT is suited to 36V deep cycle applications including off-road 4WD, caravan, marine, and commercial and industrial setups. It is not suited to under-bonnet or engine starting applications unless specifically approved by Invicta.

Can the SNL36V100BT be connected in series?
No. Invicta Bluetooth batteries cannot be connected in series. The SNL36V100BT is available as a standalone 36V solution. Up to 4 units can be connected in parallel for increased capacity.

How does the Bluetooth monitoring work?
The built-in Bluetooth module allows monitoring of charge, discharge, capacity, temperature, voltage, and BMS safety features from up to 5 metres away via a free Apple or Android application. This is particularly useful when the battery is installed in a hard-to-reach location.

What certifications does the SNL36V100BT hold?
The SNL36V100BT holds IEC62619 certification covering the complete battery including all cells and BMS, and IEC62133/UL1642 certification at the cell level. These certifications independently verify the safety and performance of the battery and its components.

What warranty does the SNL36V100BT carry?
The SNL36V100BT is backed by a 7-year full replacement warranty in approved applications, supported by SPB with over 25 years in the energy storage industry. Contact us for full warranty terms and approved application details before purchasing.
