HELIX M ONE X 24 Volt | 1 Channel Digital Amplifier | 1030W RMS 1Ω Stable

HELIX M ONE X  24 Volt | 1 Channel Digital Amplifier | 1030W RMS 1Ω Stable

Small. Efficient. Commercial Ready.

Experience compact 24V digital power with HELIX M ONE X 24V Edition's advanced Class D technology—delivering 1030W RMS output in minimal dimensions with smart high-level input featuring ADEP circuit protection and TwinPower Link capability.

Small, efficient and uncompromisingly stable – the M ONE X – 24V Edition is a highly compact monoblock for subwoofer applications. Designed from latest Class D technology this tiny amp can easily control speakers with 1 Ohm impedance. Its current capability makes the M ONE X – 24V Edition a perfect partner for 2 x 2 Ohms subwoofers, where both voice coils are connected in parallel. And for even more output power, two M ONE X – 24V Edition amplifiers can be combined to one single powerhouse – thanks to the TwinPower Link. In addition a comprehensive and stunningly practical feature set leaves nothing to be desired. Last but not least installation will be a no-brainer due to the minimal dimensions.

M ONE X 24 Volt Features:

• Small footprint Class D amplifier with up to 1,180 Watts RMS output power @ 1 Ohm for easiest combination with all 2 x 2 Ohms subwoofers connected in parallel
• Start-Stop capability down to 12V supply voltage
• Smart highlevel input with ADEP circuit and Auto Turn-On function
• Integrated, active crossover with lowpass, bass boost, subsonic and phase control
• TwinPower Link for connecting two amplifiers in bridged mode
• Bass remote control for volume adjustment
• Low heat dissipation thanks to extraordinary efficiency
• 24V power supply designed for commercial and truck applications
• Advanced Diagnostics Error Protection (ADEP) prevents OE radio error messages
• Maintains factory features like fader function with OE integration
• Compact dimensions for easy installation in tight spaces
• Professional Class D efficiency with minimal power consumption
• Auto Turn-On function for seamless operation
• Ultra-compact design without performance compromise
• Wide operating voltage range (18-36V) for commercial reliability


Specifications:

• Channels: 1 Channel | Mono
• Built-in DSP: No
• RCA Input: 2x RCA
• High-Level Input: 2x High level
• Power W RMS/ch | 4Ω: 400W
• Power W RMS/ch | 2Ω: 700W
• Power W RMS/ch | 1Ω: 1030W
• Max Output Power: 1180W RMS @ 1Ω
• Class: D
• Max Input Sensitivity: 13V (High-level), 6V (RCA)
• THD+N: 0.20%
• RCA Out: 0x | No Pre-out
• Frequency Response: 10 Hz - 250 Hz
• Bass Boost: 0-12 dB / 30-80 Hz
• Lowpass: 50 Hz - 250 Hz adjustable
• Subsonic: 10 Hz - 50 Hz adjustable
• Phase: 0-180° adjustable
• Signal-to-Noise Ratio: 95 dB (A-weighted)
• Damping Factor: 150
• Operating Voltage: 18-36V (max. 5 sec. down to 12V)
• Operating Temperature: -40°C to +70°C
• Dimensions (H x W x D): 50 x 320 x 154mm
• Fuse: 3 x 20A Maxi-fuse (APX)
• Power Rating: DC 24V ⎓ 53A max.
• Idle Current: 400mA


Scope of Delivery:

• 1 x Amplifier HELIX M ONE X – 24V Edition
• 1 x Cable remote control
• 1 x Mounting material
• 1 x Instruction manual


Perfect for:

• Commercial vehicle installations, truck audio systems, 24V system applications, fleet installations, heavy-duty mobile equipment, and any 24V application requiring maximum power output with minimal footprint and professional reliability.
