Fusion MS-AP41200 4 Channel Marine Amplifier Apollo

It’s The Difference Between Hearing The Music And Feeling It

These efficient, easy-to-install amplifiers work with your compatible Fusion stereo system1 and let you choose from Monoblock, multichannel, and zone amplifier options.

The Apollo amplifiers are designed to produce impressive power with less drain on your battery. The Monoblock produces 650-watt RMS and the 4/6/8 channel amplifiers produce 150-watt RMS per channel.

These amplifiers use the Easy Tune feature2, which automatically regulates audio settings. So, you can get the best quality sound without making manual adjustments.

Some amplifiers distort audio when they add power. Ours are specifically designed with minimal distortion and noise, so you can enjoy high-quality audio, even at higher volumes.

Identify electrical issues at a glance. These indicator lights will show you issues with electrical currents and shorts as well as temperature.

Easily install the amplifiers on board with the included mounting brackets.

The ignition-protected design helps prevent potential damage from overheating.

The amplifier’s circuit board has been specially coated to provide extra protection from the marine elements.

You can connect up to two speakers per channel, increasing setup options.

The amplifiers are designed to last season after season. They have been tested for a high level of protection against salt fog, temperature, vibration, and UV.

Specifications:

• Physical Dimensions Without Bracket (Lxwxh): 9.25″ X 7.06″ X 1.75″ (235 X 180 X 45 Mm
• Physical Dimensions With Bracket (Lxwxh): 9.25″ X 7.06″ X 2.13″ (235 X 180 X 50 Mm)
• Weight: 4.85 Lb (2.2 Kg)
• Water Rating: Ipx2
• Amplifier Class: Class-d
• Cea-2006 Power Rating: 150 Watts Rms X4 @ 14.4v Input 4 Ohm < 1% Thd
• Total Rated Power Output - 2 Ohm (Watts) :290 Watt Rms X 4 @ 14.4 V Input - 2 Ohm < 1% Thd
• Peak Power (Watts): 4 Channel: 580 Watt Rms X 2 @ 14.4 V Input - 4 Ohm Bridged < 1% Thd
• Total Rated Power Output - 4 Ohm Bridged (Watts): 1200 Watts
• Input Sensitivity: 1.3 V Rms
• Input Impedance: 22k
• Operating Voltage: 10.8 V - 16 V
• Current Consumption (Standby): < 1.15 A @ 14.4 V Input
• Current Consumption (Idle): < 0.89 A @ 14.4 V Input
• Current Consumption (Max): 53 A
• Fuse Rating: 85 A Electronic Fuse (No Replacement Necessary
• Ignition Safety Protected (Sae J1171): Yes
• Protection Circuits Reverse Voltage, Input Under/over Voltage, Over Temperature, Output Short Circuit
• Operating Temperature Range: From 0° To 50° C
• Warranty: 3 Years

What's in the Box:

• One Apollo 4-channel Amplifier
• One Mounting Bracket
• One Power Connector
• Two Speaker Connectors With High-power Mode Adaptors
• Four 8-gauge, Flat-head Self-tapping Screws
• Four 8-gauge, Pan Head Self-tapping Screws (For Mounting Bracket)
• Four Screw Covers
• Mounting Template
• Installation Instructions
• Important Safety And Product Information (ISPI)
