DNA Audio SWPTY28KEY Steering Wheel Control Harness 28 Pin With Key 1 & 2 Input To Suit Toyota Vehicles - Professional Integration Solution

DNA Audio SWPTY28KEY Steering Wheel Control Harness 28 Pin With Key 1 & 2 Input To Suit Toyota Vehicles - Professional Integration Solution

Retain your Toyota's factory steering wheel controls with the DNA Audio SWPTY28KEY harness, specifically designed for 28-pin Toyota steering wheel control systems. This precision-engineered harness enables direct connection between your factory Toyota steering wheel controls and compatible aftermarket head units, maintaining full button functionality without sacrificing modern entertainment features.

Built with comprehensive pin assignments including VSS output and reverse trigger outputs, the SWPTY28KEY harness provides complete integration for Toyota vehicles equipped with 28-pin steering wheel control systems. Compatible with major aftermarket head unit brands including JVC, Kenwood, Pioneer, Alpine, and Sony units with SWC learning features.

DNA Audio SWPTY28KEY Key Features & Benefits:

• Toyota 28-Pin Specific: Designed exclusively for Toyota vehicles with 28-pin steering wheel control systems
• Direct Factory Connection: Enables plug-and-play connection to factory Toyota steering wheel harnesses
• Multi-Brand Compatibility: Works with JVC, Kenwood, Pioneer, Alpine, and Sony head units with SWC learning
• Complete Integration: Includes VSS output and reverse trigger outputs for comprehensive functionality
• Dual Key Input: Features both Key 1 and Key 2 inputs for enhanced control compatibility
• Professional Wiring: Colour-coded wires with 3.5mm jack for reliable connections
• SWC Learning Ready: Compatible with head units that include steering wheel control learning features

Professional Applications:

• Toyota Steering Wheel Control Retention: Essential for maintaining factory button functionality
• Workshop Installs: Professional-grade solution for complete steering wheel control integration
• Aftermarket Head Unit Upgrades: Enables modern stereo installation while retaining factory controls
• DIY-Friendly Projects: Comprehensive wiring solution for home installations
• Complete Audio System Integration: Works with VSS and reverse camera systems

Technical Specifications:

• Model: DNA Audio SWPTY28KEY
• SKU: SWPTY28KEY
• Type: Vehicle-Specific 28-Pin Steering Wheel Control Harness
• Vehicle: Toyota vehicles with 28-pin steering wheel control systems
• Pin Configuration: 28-pin direct factory connection
• Head Unit Compatibility: JVC, Kenwood, Pioneer, Alpine, and Sony (SWC learning required)
• Additional Outputs: VSS output and reverse trigger outputs
• Key Inputs: Key 1 and Key 2 input support
• Connection: 3.5mm jack included
• Packaging: Poly bag with barcode sticker
• Brand: DNA Audio installation accessories series

Wire Color Assignments:

• Green: Handbrake Output
• Purple/Black: Reverse Output
• Pink: Speed Pulse (VSS)
• White: SW Key 1
• Grey: SW Key 2
• Purple: SW Ground
• Connection: 3.5mm Jack

Compatible With / Goes Well With:

• JVC, Kenwood, Pioneer, Alpine, and Sony head units with SWC learning
• Toyota vehicles with 28-pin steering wheel control systems
• Aftermarket head units requiring steering wheel control integration
• VSS-compatible navigation and head unit systems
• Reverse camera integration systems
• Professional installation wiring tools

Installation Applications:

• Complete Steering Wheel Control Retention: Maintains all factory button functionality
• Aftermarket Head Unit Integration: Essential for modern stereo installations
• Professional Installations: Workshop-grade solution for comprehensive integration
• VSS and Reverse Integration: Supports speed pulse and reverse trigger functionality
• DIY Upgrades: Complete wiring solution with colour-coded connections

For professional auto sparks and Toyota owners with 28-pin steering wheel control systems seeking complete factory control retention with aftermarket head units, the DNA Audio SWPTY28KEY delivers the essential integration solution. With DNA's comprehensive wiring design and multi-brand compatibility, it's the smart choice for achieving professional results while maintaining all factory steering wheel functionality.

Frequently Asked Questions

How do I know if my Toyota has a 28-pin system?

Check your factory steering wheel control connector - this harness is specifically for Toyota vehicles with 28-pin steering wheel control harnesses.

Will this work with my aftermarket head unit?

This harness is compatible with JVC, Kenwood, Pioneer, Alpine, and Sony head units that include SWC (steering wheel control) learning features.

What is the SWC learning feature?

SWC learning allows your aftermarket head unit to recognize and program the functions of your factory steering wheel control buttons.

Do the VSS and reverse outputs work automatically?

Yes, VSS (speed pulse) and reverse trigger outputs are pinned to the 28-pin plug and will function with compatible head unit systems.

Can I install this myself?

Installation requires electrical knowledge and understanding of steering wheel control systems. Professional installation is recommended for optimal results.
