DNA 7 Inch LCD 4 Channel Quad Rearview Screen

DNA 7 Inch LCD 4 Channel Quad Rearview Screen

Professional multi-camera monitoring solution for commercial vehicles and caravans. This high-resolution 4-channel quad picture TFT-LCD monitor is ideal for multiple camera applications delivering versatile viewing options with 11 different image modes, from full screen viewing to multiple split screen configurations. Featuring 7-inch TFT-LCD display with 16:9 aspect ratio and 800 (RGB) x 480 pixel resolution supporting both PAL and NTSC video systems automatically, 4 camera inputs with 4 triggered inputs for each camera position (front, rear, left, right), and dash-mountable design with U-shape bracket and large removable sun visor. Built for demanding commercial applications including caravans, buses, and truck installations where large viewing screen or multiple camera viewing is required, this monitor features illuminated touch front panel buttons for intuitive operation, inbuilt speaker for audio monitoring, IR remote control for convenient operation, and 4-pin water-resistant lockable camera connections ensuring reliable all-weather performance. Image customization options include UP/Down and Left/Right mirror adjustments for flexible camera orientation, operates across wide voltage range (12V to 24V DC ±10%) suitable for various vehicle electrical systems, low 5W current consumption for energy efficiency, and rugged construction rated for extreme operating temperatures (-20°C to +70°C). Compact dimensions (180mm W x 121mm H x 23mm D) provide professional installation flexibility for fleet vehicles, recreational vehicles, and heavy commercial transport applications demanding comprehensive visual awareness and safety monitoring capabilities.

Product Overview

This high resolution 4 Channel quad picture TFT-LCD monitor is ideal for multiple camera applications with 11 different image views, from full screen viewing and multiple split screen viewing. Includes front panel touch buttons with a large removable sun visor and is ideal for Caravans, Buses and Truck installations where a large viewing screen or multiple camera viewing is required.

Important Notes:

4 Separate Cameras Required: This monitor requires up to 4 separate cameras (not included) for full functionality. Each camera input has dedicated trigger wire allowing automatic camera activation based on vehicle operation (reverse gear, turn signals, brake lights). Monitor functions with 1-4 cameras connected, but all viewing modes require appropriate number of cameras installed.

Professional Installation Recommended: Proper installation requires mounting monitor securely, routing 4 camera cables through vehicle, connecting trigger wires to appropriate vehicle circuits (reverse lights, indicators, brake lights), and testing all camera angles and switching functions. Incorrect wiring may cause camera malfunction, incorrect triggering, or electrical issues. Professional installation ensures optimal camera positioning, secure weatherproof connections, and proper integration with vehicle electrical systems.

Wide Voltage Range Compatibility: Operates on 12V to 24V DC (±10%) suitable for passenger vehicles (12V), commercial trucks (24V), buses, and caravans. Verify voltage compatibility with your vehicle electrical system before installation. Do not exceed voltage range as this may damage monitor electronics.

Camera Compatibility Requirements: Designed for standard analog cameras with composite video output compatible with PAL or NTSC video systems. Digital cameras, IP cameras, or cameras with non-standard outputs are not compatible. Ensure camera outputs match monitor inputs before purchase.

Environmental Operating Limits: Rated for -20°C to +70°C operating temperature suitable for Australian climate conditions. However, extreme direct sunlight exposure or enclosed cabin temperatures exceeding 70°C may cause temporary shutdown or display degradation. Use provided sun visor and ensure adequate ventilation around monitor for reliable operation.

Key Features

7 Inch TFT-LCD Display - High-resolution display with 16:9 aspect ratio and 800 (RGB) x 480 pixel resolution providing clear detailed images for safety monitoring.

4 Camera Inputs with Triggered Activation - Four independent camera inputs with dedicated trigger wires for each position (front, rear, left, right) allowing automatic camera switching based on vehicle operation.

11 Different Image Modes - Versatile viewing options including full screen single camera, dual split screen, triple split screen, quad split screen, and various layout combinations for comprehensive vehicle monitoring.

AUTO PAL & NTSC Video System - Automatically detects and switches between PAL and NTSC video standards ensuring compatibility with wide range of camera types.

Dash Mountable with U-Shape Bracket - Professional mounting bracket included for secure dashboard or windscreen installation in various vehicle types.

Large Removable Sun Visor - Included sun visor reduces glare and improves screen visibility in bright sunlight conditions, removable when not required.

Illuminated Touch Front Panel Buttons - Intuitive front panel touch buttons with illumination for easy operation in low-light conditions without requiring remote control.

Inbuilt Speaker - Integrated speaker provides audio monitoring capability when paired with cameras featuring audio output.

IR Remote Control - Wireless infrared remote control included for convenient operation from driver position without reaching for monitor.

4-Pin Water-Resistant Lockable Camera Connections - Professional-grade weatherproof connectors with locking mechanism ensuring reliable connections in harsh environmental conditions.

Image Flip Options - UP/Down and Left/Right mirror image adjustments allowing flexible camera mounting orientations and correcting inverted images.

Wide Voltage Range Operation - Operates on 12V to 24V DC (±10%) compatible with passenger vehicles, commercial trucks, buses, and caravans.

Low Power Consumption - Only 5W current consumption minimizing electrical system load and suitable for extended operation.

Extreme Temperature Rating - Operating temperature range -20°C to +70°C suitable for Australian climate conditions and commercial vehicle environments.

Compact Dimensions - 180mm W x 121mm H x 23mm D compact size allows flexible installation locations while maintaining large viewing area.

Commercial Vehicle Applications - Ideal for caravans, buses, trucks, fleet vehicles, heavy equipment, and recreational vehicles requiring comprehensive visual awareness.

Professional Packaging - Supplied in display box packaging suitable for retail presentation and safe transport.

Technical Specifications

Frequently Asked Questions

Q: How many cameras do I need and what cameras are compatible?

A: This monitor supports 1 to 4 cameras (cameras sold separately). You can start with one camera and add more as needed. Compatible with standard analog cameras featuring composite video output (RCA or aviation-style connectors) supporting PAL or NTSC video systems. Reverse cameras, side cameras, front cameras, and blind-spot cameras all work if they output standard analog video. Digital cameras, IP cameras, or HD-SDI cameras are not compatible. Ensure cameras have 4-pin aviation-style connectors or compatible wiring for connection to monitor's water-resistant lockable ports.

Q: How does the automatic camera switching work?

A: Each of the 4 camera inputs has a dedicated trigger wire. Connect trigger wires to appropriate vehicle circuits: rear camera trigger to reverse light power, left/right camera triggers to turn signal circuits, front camera trigger to brake or ignition. When trigger receives power (e.g., reverse gear engaged), monitor automatically switches to corresponding camera view. You can also manually select cameras using front panel buttons or IR remote. Trigger sensitivity and switching behavior may require professional adjustment during installation.

Q: Will this work in my 12V car and 24V truck?

A: Yes, the monitor operates on 12V to 24V DC (±10% tolerance) making it compatible with passenger vehicles (12V), light commercial vehicles (12V), heavy trucks (24V), buses (24V), and caravans (12V or 24V). The wide voltage range eliminates need for separate models for different vehicle types. Ensure proper fusing (recommended 1-2A fuse) on power supply line for protection.

Q: What are the 11 different image modes?

A: The 11 viewing modes include: (1) Single full-screen camera 1, (2) Single full-screen camera 2, (3) Single full-screen camera 3, (4) Single full-screen camera 4, (5) Dual horizontal split (2 cameras side-by-side), (6) Dual vertical split (2 cameras top/bottom), (7) Triple screen with one large + two small, (8) Triple screen alternate layout, (9) Quad split (4 cameras equal size), (10) Quad split with one emphasized camera, (11) Quad split alternate layout. Specific layouts may vary - consult user manual for detailed view configurations. Use front panel buttons or IR remote to cycle through modes.

Q: Where should I mount this monitor and how difficult is installation?

A: Common mounting locations include dashboard (using U-bracket), windscreen (with suction mount - not included), or custom console mounting. Choose location providing clear driver visibility without obstructing critical vehicle controls or sightlines. Professional installation is strongly recommended as it requires: (1) Routing 4 separate camera cables through vehicle, (2) Mounting cameras with proper aiming angles, (3) Connecting trigger wires to vehicle electrical circuits (reverse lights, indicators), (4) Securing all connections with weatherproof methods, (5) Testing all camera views and automatic switching functions. DIY installation possible for experienced automotive electrical enthusiasts, but professional installation ensures optimal camera positioning, reliable weatherproof connections, and compliance with local regulations regarding in-vehicle displays.
