IC650 Industrial Battery Charger

The IC650 Battery Charger provides 650 watts of DC output power and is available in three output voltages —24V, 36V and 48V for usage in applications such as lift trucks, floor cleaning machines, aerial work platforms, and electric scooters. Delta-Q intends to release higher voltage variants in the future to meet customer demand.

Specifications:

• 36 Volts
• 18.1 Amps maximum, 650 W
• Deep discharge recovery mode minimum voltage 1.8 volts
• For Lead-acid (Wet/AGM/Gel)*
• AC input voltage - 120 VAC / 270 VAC at 50/60 Hz
• AC input connector US IEC320/C14 (requires country-specific cord)
• DC output connector M6 threaded fasteners for ring terminals
• Multicolor LED for AC & Battery status (<80% / >80% / completion), Charging, Alarm, Fault
• Stores up to 25 user-­selectable charge algorithms, comes with 17
• Dimensions: 9.9" x 7.3" x 3.1"
• Weight: 6.5 lbs.
• *These are not recommended for Lithium batteries and we do not support or program for Lithium.

Note:

• This model includes the COMM port.
