DD Audio DD-612E 12" 2400W 600 Series Power Tuned Subwoofer

Great Entry Point For A Higher Performance System Design!

12" Power Tuned Subwoofer

The 600 Series is a great entry point for a higher performance system design that keeps the vehicle as close to stock as possible. These subs will perform like a boss on as little as 300-600 Watts, meaning even multiple woofer systems can be driven with one moderate powered amplifier. This keeps electrical upgrades minimal with less added strain on the vehicle.

With a high energy, double stack motor paired with a laminated triple layer poly cotton spider suspension the 600 Series works best with vented and multi-order enclosures. The new E revision features an increased motor size, increased top plate thickness, and increased voice coil winding length.

The 600 Series subwoofers are not for the faint of BASS! From the top down they are built for extreme sonic performance. Heavy duty double stack magnet motors and long throw voice coils handle the power while Power Tuned suspensions with EROM surrounds and a progressive dual spider system keep the moving parts linear and distortion free during high excursion play. The 600 Series subs work best in vented and multi order enclosures.

Specifications:

• Speaker Size (In): 12
• Speaker Size (mm): 304.8
• Watts RMS: 500 - 800
• Watts Peak: 2400
• Impedance: D2 / D4
• VCD (In): 2.5
• Piston Diameter (In): 10.125
• Fs (Hz): 32.3
• QMS: 4.646
• QES: 0.472
• QTS: 0.428
• VAS: 40.22
• Xmech (In): 2.6
• Xmax (mm): 15
• Frame OD (In): 12.875
• Frame OD With Gasket (In): 13
• Mounting Diameter (In): 11.5
• Mounting Depth (In): 6.75
• Motor Diameter (In): 7
• Motor Depth (In): 3
• Magnet Weight (Oz): 170
• Woofer Displacement (CuFt): 0.09
• Ported Enclosure (CuFt): 1.75 - 2.75
• Shipping Weight (Lbs): 28
