DB Drive WDXPRO-AS10 - Powered 10" Active Subwoofer with 1200W Peak Power

DB Drive WDXPRO-AS10 - Powered 10" Active Subwoofer with 1200W Peak Power

Product Overview

Unleash deep, clean bass with the DB Drive WDX PRO 10" Active Subwoofer — engineered for precision and power. Delivering up to 1200 watts of dynamic power and 350 watts RMS, this all-in-one bass solution is packed with features to customize your sound. Fine-tune your audio with adjustable input sensitivity, a variable low-pass filter (50Hz–150Hz), and bass boost up to 18dB at 45Hz. Built for versatility, it supports both low-level RCA and high-level factory radio inputs, plus a remote gain control and selectable phase shift (0°–180°) for seamless integration. The active subsonic filter at 20Hz and multi-fault protection circuitry ensure reliable, distortion-free performance. With a MOSFET power supply, the WDX PRO 10" delivers bass that hits hard and clean — every time.

Key Features

Adjustable Input Sensitivity

Dial in the perfect input level to match your head unit output and prevent distortion, ensuring optimal signal transfer from any source.

Low Level RCA Inputs

Connect directly to aftermarket stereos with pre-amp outputs for clean signal transfer and maximum sound quality.

Factory Radio High Level Inputs

Plug straight into factory speaker wires without needing adapters or converters, making installation simple and cost-effective.

Variable Low-Pass Filter (50Hz - 150Hz)

Fine-tune your crossover point between 50Hz and 150Hz to blend perfectly with your front speakers and eliminate frequency overlap.

Variable Bass Boost (0 - 18dB @ 45Hz)

Add up to 18dB of punch at 45Hz when you need that extra thump for bass-heavy tracks without distortion.

Selectable Phase Shift (0° - 180°)

Adjust from 0 to 180 degrees to eliminate bass cancellation and maximize output in your vehicle's unique acoustic environment.

Remote Gain Control

Mount the level controller near your seat for quick bass adjustments on the fly without reaching for the subwoofer.

Active Subsonic Filter @ 20Hz

Protects your subwoofer from inaudible frequencies below 20Hz that waste power and cause distortion or damage.

Multi-Fault Protection Circuitry

Built-in safeguards against short circuits, overheating, and overload for long-lasting reliability and peace of mind.

MOSFET Power Supply

High-efficiency power design delivers consistent, clean amplification without draining your electrical system or causing voltage drops.

Technical Specifications

Power Output

• Dynamic Power: 1200 Watts
• RMS Power: 350 Watts

Audio Controls

• Variable Low-Pass Filter: 50Hz - 150Hz
• Variable Bass Boost: 0 - 18dB @ 45Hz
• Active Subsonic Filter: @ 20Hz
• Phase Shift: 0° - 180° Selectable

Connectivity

• Low Level RCA Inputs
• High Level Speaker Inputs
• Remote Gain Control Port

Protection Features

• Multi-Fault Protection Circuitry
• Thermal Protection
• Short Circuit Protection
• Overload Protection

Power Supply

• MOSFET Power Supply Design
• Efficient Power Conversion

Dimensions

• Length: 13.50" / 343mm
• Width: 10.25" / 260.35mm
• Height: 3.25" / 82.55mm
• Subwoofer Size: 10 inches

Frequently Asked Questions

Can I connect this subwoofer to my factory stereo without replacing my head unit?

Yes! The WDXPRO-AS10 features high-level speaker inputs that allow you to tap directly into your factory speaker wires without needing RCA pre-amp outputs. This makes installation simple and cost-effective while maintaining excellent sound quality from your factory stereo system.

What's the difference between the low-pass filter and bass boost controls?

The low-pass filter (50Hz-150Hz) determines which frequencies your subwoofer reproduces, helping it blend seamlessly with your front speakers. The bass boost (0-18dB @ 45Hz) adds extra emphasis at a specific frequency for more punch. Use the low-pass filter for proper system integration, and add bass boost sparingly for personal taste.

How much power does this subwoofer need from my vehicle's electrical system?

The WDXPRO-AS10 delivers 350 watts RMS with efficient MOSFET power supply technology that minimizes electrical system strain. Most vehicles with factory alternators can support this subwoofer without requiring electrical upgrades. The multi-fault protection circuitry prevents electrical issues during operation.

What does the phase shift control do and when should I adjust it?

Phase shift (0°-180°) adjusts the timing of your subwoofer's output relative to your front speakers. If bass sounds weak or hollow in your vehicle, adjusting the phase can eliminate cancellation caused by your vehicle's acoustics. Experiment with phase settings while playing bass-heavy music to find the position that produces the strongest, cleanest bass response.

Do I need a separate amplifier to power this subwoofer?

No! The WDXPRO-AS10 is a powered active subwoofer with a built-in 1200W peak / 350W RMS amplifier. Simply connect audio inputs, power, and ground — no external amplifier required. This all-in-one design saves installation time, space, and cost compared to passive subwoofers that require separate amplification.
