Axis HD5120CK 5" Heavy Duty Monitor With High-Resolution Reversing Camera Kit

Axis 5" Heavy Duty Monitor With High-Resolution Reversing Camera Kit: Offers Clear Image & Enhanced View When Reversing!

5” High-Resolution Camera Kit

A High-Resolution 12/24V monitor kit that offers a clear image and enhanced view when reversing. Its Heavy Duty construction makes it suitable for trucks, machinery and vehicles. The HD5120CK also has the added flexibility of connecting up to 2 cameras.

Axis HD5120CK Specifications:

• Monitor:
  • TFT Panel: New Grade A LCD
  • LCD Size: 5-Inch (Diagonal)
  • Display Format: 16:9
  • Resolution: 1024 x 600
  • Brightness: < 500 CD/M2
  • Viewing Angles: 70° Left/Right/Up/Down
  • Video System: Auto PAL/NTSC Select
  • Video Connect: 2 x 4-Pin (Male)
  • Compatibility: Standard & High-Resolution Camera’s
  • Buttons: Touch Sensitive
  • Connection Type: Universal Standard 4-Pin Configuration (M)
  • Camera Triggers: 2
  • Monitor View: Normal/Mirror/Flip/Mirror-Flip Image Select
  • Guidelines: Selectable On/Off (Camera 2 Input Only)
  • Audio: Camera 2 Input Only
  • Main Menu: Brightness/Contrast/Colour/Photosensitive (Dimmer), Language, Default Setting, Volume, RLUD, (Screen Orientation), VCOM (Exposure), Ruler Setting (Guidelines), AccTime, Version
  • Operating Temp: -20°C ~ +70°C
  • Power Input: 10-32V DC (Negative Ground)
  • Dimensions: 132.2mm (W) x 94.3mm (H) x 22.45mm (D) - Excluding Bracket & Visor
• Camera:
  • Sensor: 1/3” IMX225LQR-C
  • Diagonal Viewing Angle: 140°
  • Horizontal Viewing Angle: 120°
  • Signal System: PAL
  • Effective Pixels: 1280 (H) x 720 (V)
  • Resolution: 720P
  • Orientation: Mirror Image
  • Night Vision: 18 Infrared LED’s
  • Illumination: 0.001 Lux With IR On
  • Ingress Protection: IP69K
  • Integrated Microphone: Yes
  • Operating Temp: -20 ~ 70° C
  • Power Consumption: 3W, 250mA
  • Connection Type: Universal Standard 4-Pin Female
  • Power Supply: 12V DC
  • Dimensions: 98.3mm (W) x 67.7mm (H) x 68mm (D) - Including Bracket
