AudioControl PNW-XN3 - PNW Series 3-Way Crossover Network

AudioControl PNW-XN3 - PNW Series 3-Way Crossover Network | Professional 3-Way System Creation

Professional 3-way crossover network with 2nd order Linkwitz-Riley design enabling creation of advanced 3-way speaker systems by combining PNW-275 midrange with PNW component sets

Product Overview

The AudioControl PNW-XN3 delivers professional 3-way system creation through expertly engineered crossover network designed specifically to transform PNW component speaker systems into advanced 3-way configurations. This professional crossover features 2nd order Linkwitz-Riley design with Zobel networks for precise frequency division at 350Hz and 4kHz, enabling seamless integration of PNW-275 midrange speakers with either PNW-65CS2 or PNW-69CS2 component sets, providing 150W RMS power handling with configurable 2, 4, or 6 channel input capability and adjustable attenuation controls for tweeter and midrange optimization in demanding audiophile applications.

What Makes This Crossover Special

• Advanced 3-Way System Creation – Transforms existing PNW component systems into professional 3-way configurations by adding PNW-275 midrange drivers, creating superior frequency separation and enhanced midrange clarity compared to standard 2-way designs
• Professional Linkwitz-Riley Design – Features 2nd order Linkwitz-Riley crossover slopes with Zobel networks for precise frequency division (350Hz LP/350-4kHz BP/4kHz HP) and -12dB/octave slope, ensuring phase-coherent transitions between drivers without overlap or gaps
• Flexible Configuration Options – Configurable from 2, 4, or 6 channels of input with adjustable attenuation controls (0/-3/-6dB) for tweeter and midrange optimization, accommodating various amplifier configurations and system tuning requirements
• Premium Component Integration – Specifically engineered for seamless integration with PNW-275 midrange, PNW-65CS2, PNW-69CS2 component sets, and PNW-1 tweeters, providing matched impedance and frequency characteristics for optimal system performance

Technical Specs

• Crossover Type: 2nd order Linkwitz-Riley with Zobel networks
• Filter Configuration: High-pass/Band-pass/Low-pass design
• Crossover Frequencies: 350Hz low-pass, 350-4kHz band-pass, 4kHz high-pass
• Slope: -12dB/octave for all frequency divisions
• Power Handling: 150W RMS, 200W maximum
• Attenuation Controls: 0/-3/-6dB for tweeter and midrange adjustment
• Input Configuration: Configurable from 2, 4, or 6 channels
• Compatible Speakers: PNW-275 (midrange), PNW-65CS2/PNW-69CS2 (woofer), PNW-1 (tweeter)
• Frequency Divisions: 350Hz (woofer to midrange), 4kHz (midrange to tweeter)
• Construction: Professional-grade components with premium crossover design
• Dimensions: 10.6" x 5.12" x 1.13" (270 x 130 x 28.6mm)
• Recommended Configurations: PNW-65CS2 + PNW-275 or PNW-69CS2 + PNW-275
• Driver Optimization: Precision-tuned for PNW speaker characteristics and impedance

Frequently Asked Questions

What PNW speakers does this crossover work with?

The PNW-XN3 is specifically designed to create 3-way systems using PNW-275 midrange speakers combined with either PNW-65CS2 or PNW-69CS2 component sets, plus PNW-1 tweeters for complete 3-way performance.

How does a 3-way system improve over 2-way designs?

3-way systems provide dedicated midrange drivers for superior vocal and instrumental reproduction, reducing distortion and intermodulation between frequency ranges while enabling each driver to operate in its optimal frequency band.

What amplifier configuration is required?

The crossover is configurable from 2, 4, or 6 channel inputs, allowing use with stereo amplifiers (bi-amp/tri-amp), multi-channel amplifiers, or multiple amplifier configurations depending on desired system complexity.

What do the attenuation controls adjust?

The 0/-3/-6dB attenuation controls allow fine-tuning of tweeter and midrange output levels to match room acoustics, personal preferences, and system balance for optimal frequency response.

Can I use this crossover with non-PNW speakers?

While designed specifically for PNW speakers, the crossover frequencies and impedance characteristics are optimized for PNW components. Use with other speakers may require different crossover points for optimal performance.

What's the advantage of Linkwitz-Riley design with Zobel networks?

Linkwitz-Riley crossovers provide flat frequency response and perfect phase alignment at crossover points, while Zobel networks ensure proper impedance compensation for stable amplifier loading and optimal driver performance.

How It Works

Professional 3-Way Integration System – Connect the PNW-XN3 between your amplifier(s) and PNW speakers according to your chosen configuration (2/4/6 channel input). The crossover divides frequencies at 350Hz (woofer/midrange) and 4kHz (midrange/tweeter) using 2nd order Linkwitz-Riley slopes. Adjust attenuation controls for tweeter and midrange to optimize system balance. The result is professional 3-way performance with dedicated frequency ranges for each driver.

Compatible With / Goes Well With

Speaker Compatibility: PNW-275 midrange (required), PNW-65CS2 or PNW-69CS2 component sets, PNW-1 tweeters

Amplifier Compatibility: Stereo amplifiers, multi-channel amplifiers, multiple amplifier configurations supporting bi-amp or tri-amp operation

System Integration: Advanced PNW component systems, audiophile installations, professional 3-way speaker builds

Professional Installation: Authorized AudioControl dealers, advanced component system specialists, audiophile installation experts
