Aerpro SWMB8C SWC Interface Mitsubishi Challenger Colt and Triton MN
Click to open expanded view
AERPRO logo

Aerpro SWMB8C SWC Interface Mitsubishi Challenger Colt and Triton MN

SKU: SWMB8C
Price
$119.99
Buy now, pay later
  • image
  • image
  • image

Shipping information

We offer fast and reliable shipping options to ensure that your order arrives in a timely manner. Our dedicated team works diligently to process and ship your items as quickly as possible.

Here are some key points to note about our shipping policy:

Standard Shipping

  • Frankies offers a $15.95 flat rate for Australia-wide shipping, no matter how many items you order. Some larger or heavier items may incur an additional fee, which will be communicated to you when your order is processed.
  • While we endeavour to dispatch all orders promptly, please be advised that due to the current national fuel shortages in Australia and the resulting pressure on logistics networks, order processing and dispatch may take up to 7 business days. We are not liable for delays caused by third-party freight carriers or fuel-related logistical disruptions. By placing an order, you acknowledge that delivery timeframes may be extended beyond our standard estimates during this period.

Estimated delivery times:

  • WA, NT, and TAS: currently experiencing longer shipping times
  • Holiday periods (e.g. Christmas): deliveries may be delayed due to increased freight volumes

Express Shipping

  • Express shipping is available and calculated based on your delivery location, as well as the size and weight of your order. To receive an accurate quote, please contact our Albion Park Rail store and request an "express shipping quote." Our team will promptly assist with pricing and availability. Payment for express shipping can be securely arranged over the phone.

Share this product

Share Post Pin E-mail

Product features

Aerpro SWMB8C Steering Wheel Control Interface for Mitsubishi Challenger Colt and Triton MN GLX-R Non-Amplified Vehicles

The Aerpro SWMB8C is an analogue steering wheel control (SWC) interface for select Mitsubishi vehicles without OEM amplified audio systems. It retains factory steering wheel audio controls after an aftermarket head unit is installed. Phone button and voice assistant button support are not available. Not suitable for OEM amplified vehicles. No wire cutting is required.

Product overview

The SWMB8C bridges the factory steering wheel control signals to the aftermarket head unit using an analogue interface and SW patch lead. A vehicle-specific plug connects directly into the existing Mitsubishi wiring without cutting or modifying the factory loom. The aftermarket head unit must be SWC compatible, and steering wheel control functions may vary from the original OEM functions.

This interface suits non-amplified variants only. If your Mitsubishi is fitted with an OEM amplified audio system, the SWMB8C is not suitable an alternative interface will be required. No outputs are provided for reverse trigger, park brake, speed pulse, illumination or amplifier remote. OEM AUX input and OEM amplified system retention are not supported. Phone button and voice assistant functionality are also not available on this interface. Custom button remapping is available if needed using a USB-C cable (sold separately). Pairing with the Aerpro APP8 Headunit Secondary ISO Harness (sold separately) is recommended for a complete installation.

Features and benefits

Retains factory steering wheel controls: Allows the factory steering wheel audio controls to function with an aftermarket head unit, keeping hands on the wheel and eyes on the road.

For non-amplified Mitsubishi vehicles only: Suited to Mitsubishi Challenger, Colt and Triton MN GLX-R vehicles without OEM amplified audio systems. Not suitable for OEM amplified vehicles.

Vehicle-specific plug, no wire cutting required: The harness includes a plug designed to connect directly into the existing Mitsubishi wiring without cutting or modifying the factory loom.

Analogue interface type: Analogue SWC interface with SW patch lead, suited to compatible aftermarket head units.

No phone or voice assistant button support: Phone button and voice assistant functionality are not available on the SWMB8C.

Custom button remapping available: Default button configuration can be remapped to suit different aftermarket head unit button assignments. Requires a USB-C cable (sold separately) and Aerpro remapping instructions.

Compatible with Aerpro APP8 ISO harness: Pairing with the Aerpro APP8 Headunit Secondary ISO Harness (sold separately) simplifies the connection between the SWMB8C and the aftermarket head unit.

Technical specs

Specification Detail
SKU SWMB8C
Brand Aerpro
Interface Type Analogue
Patch Lead Type SW
Phone Button Compatibility No
Voice Assistant Button Support No
Reverse Trigger Output No
Park Brake Output No
Speed Pulse Output No
Illumination Output No
Amp Remote Output No
OEM Amplified System Retention No
OEM AUX Input Retention No
Compatible Vehicles Non-amplified variants only (see list below)

Compatible with

Vehicle Year Range Notes
Mitsubishi Challenger 2009 to 2013 PB series
Mitsubishi Colt 2004 onwards
Mitsubishi Triton 2009 to 2012 MN series, GLX-R trim only

Not suitable for OEM amplified vehicles. The aftermarket head unit must be SWC compatible. Steering wheel control functions may vary from OEM functions. Use the Aerpro Vehicle Selector to confirm compatibility for your specific model variant before purchasing.

Frequently asked questions

How do I know if my Mitsubishi has an OEM amplified system? Mitsubishi vehicles with OEM amplified audio systems typically include Rockford Fosgate or similar branded audio mentioned in the vehicle specifications, additional amplifier modules in the boot or under seats, and a higher-end speaker system. If you are unsure whether your vehicle has an amplified system, check the vehicle's specifications or contact us before purchasing.

Is the SWMB8C suitable for all Triton MN variants? No. The SWMB8C suits only the Triton MN GLX-R trim from 2009 to 2012. Other Triton MN variants may require a different interface. Use the Aerpro Vehicle Selector to confirm the correct part for your specific Triton variant.

Does the SWMB8C support phone or voice assistant buttons? No. Neither phone button nor voice assistant button functionality is available on the SWMB8C. If these features are required, check the Aerpro range for an alternative Mitsubishi-compatible interface that includes phone or voice assistant button support.

Do I need to cut any factory wiring to install the SWMB8C? No. The SWMB8C harness includes a vehicle-specific plug that connects directly into the existing Mitsubishi wiring without any cutting or modification to the factory loom.

What is the Aerpro APP8 and do I need it? The Aerpro APP8 is a headunit secondary ISO harness that connects between the aftermarket head unit and the SWMB8C interface, simplifying the overall installation. It is sold separately and is recommended but not mandatory for the SWMB8C to function.
