Aerpro AMDMB27 9" Multimedia Receiver Mitsubishi Triton 19-24

9" Wireless CarPlay for the Modern Mitsubishi Triton MR Retains SWC, Reverse Camera, and AUX on Auto Climate Models

Product Overview

The Aerpro AMDMB27 is a complete head unit upgrade kit for the Mitsubishi Triton MR (2019–2024) fitted with auto climate control. It replaces the factory unit with a 9" capacitive touchscreen at 1024x600 resolution, adding wireless Apple CarPlay and Android Auto, built-in DAB+ digital radio, and Bluetooth V5. It retains steering wheel controls (including the phone button), the factory reverse camera (if equipped), and the factory AUX input (if equipped) with no camera or AUX signal loss after installation.

The kit includes the AM905D multimedia receiver, a gloss black/silver vehicle-specific facia kit, SWC interface harness, SWC patch lead, camera retention adaptor, and a 720P AHD universal rear camera. Note that factory USB input is not retained on this kit CarPlay and Android Auto via the head unit's USB ports replace that function. Audio is covered by 4 x 50W max output, a 13-band EQ, time alignment, and 4V/5-channel RCA preouts.

Features & Benefits

• Factory reverse camera retained (if equipped) — the camera retention adaptor preserves the factory reverse camera signal via the head unit's reverse camera input; no signal loss on reversal
• SWC retained including phone button — the SWC interface harness and patch lead retain all factory steering wheel controls including the phone button, with no manual programming required
• AUX input retained (if equipped) — factory AUX is preserved using the head unit's RCA AUX input on vehicles where fitted
• Gloss black / silver facia kit — dual-finish trim piece matched to the Triton MR interior; a step up from the plain black facia on older Triton kits
• 360-degree camera models not compatible — Triton MR variants with the optional 360-degree camera system require the Aerpro AMMB30 kit instead; this kit will not suit those vehicles
• Auto climate control models only — manual climate control Triton MR variants are not compatible with this kit
• Wireless Apple CarPlay & Android Auto — connect over Wi-Fi for maps, music, calls, and messages; wired USB connection also supported for simultaneous phone charging
• 9" capacitive touchscreen at 1024x600 resolution — a major visual and functional upgrade over the factory Triton MR display
• Built-in DAB+ digital radio — digital audio clarity and expanded station access; AM/FM with RDS, 18 FM and 12 AM presets also included
• Bluetooth V5 with HD Voice — hands-free calling, audio streaming, and phonebook access; internal and external microphone included
• 720P AHD universal rear camera included — Sony 225 1/3" CMOS sensor, 150-degree lens; provides additional camera coverage or replaces where no factory camera is fitted
• 4 x 50W max output with 5CH 4V RCA preouts — supports external amplifier integration via front/rear/sub preamp channels
• 13-band EQ and time alignment — 6 preset EQ modes plus 2 custom slots for Triton cabin-specific tuning

Technical Specs

Compatible With / Goes Well With

• Mitsubishi Triton MR (2019–2024) with auto climate control
• Not compatible with Triton MR manual climate control variants
• Not compatible with Triton MR models fitted with a 360-degree camera system — use Aerpro AMMB30 for those variants
• Use the Aerpro What Fits Your Car Guide to confirm fitment before purchasing
• Pairs well with external amplifiers via 4V 5-channel RCA preouts (front/rear/sub)
• Second camera input supports an optional front or towing camera (720P AHD compatible)

Weight

Not specified

Frequently Asked Questions

How does this differ from the AMDMB26 for the older Triton?

The AMDMB27 suits the modern Triton MR (2019–2024) with auto climate control, while the AMDMB26 suits the older Triton MN (2015). The AMDMB27 retains the factory reverse camera and uses a gloss black/silver facia, but does not retain the factory USB input — the opposite of the AMDMB26 which retained USB but not the reverse camera.

Does this kit suit Triton models with the 360-degree camera?

No — the AMDMB27 is not compatible with Triton MR variants equipped with a 360-degree camera system. The Aerpro AMMB30 kit is required for those models.

How do I know if my Triton has auto or manual climate control?

Auto climate control features a digital temperature display and automatic fan speed management. Manual climate control uses rotary knobs or sliders to set fan speed and temperature manually. If you are unsure, check your vehicle's specification sheet or the Aerpro What Fits Your Car Guide.

Is the factory reverse camera retained after installation?

Yes, if your Triton MR is factory-equipped with a reverse camera. The camera retention adaptor retains the factory camera signal via the head unit's reverse camera input. The included 720P AHD camera connects via the second camera input.

Is the factory USB input retained?

No — factory USB input is not retained on the AMDMB27. The head unit's own USB ports (CarPlay/Android Auto and media playback) replace this function. If factory USB retention is essential, check whether an alternative kit is available for your build.
